Pyrolysis Plant is used for recycling waste tire, waste plastic, waste rubber to fuel oil. According to the actual situation in every country and district, we developed different models of Pyrolysis Plants for waste tires, rubber and plastic.
Description of Continuous Waste Plastic Pyrolysis Plant:
1.Large daily capacity of 20-50 tons per day and can work 24 hours without any stop for 15-20 days.
2. Auto-loading, auto-discharging and oil coming out at the same time;
3. Only need fuel for the beginning 2-3 hours, then the sync gas generates itself is enough to support heating, saving fuel cost;
4. Low requirement on the raw materials, no need tiny granule, 5cm pieces acceptable for smooth running;
5. High efficiency condensers, more oil output, good quality oil, easy to clean.
6. Sync gas recycling system, fully burned after recycling and utilization, preventing pollution and saving fuel cost.
7. National patent smoke scrubber, can efficient remove the acid gas and dust of the smoke, environmental friendly to meet related national standards.
8. Easy to operate, need less manpower.
Features of continuous pyrolysis plant:
1. The full open door design: Speedy loading in and steel pulling out; Easily cooling down after one batch finished, saving time; No leaking with special high temperature flexible graphite packing.
2.Unique Craft Condensers: High condensing efficiency with more oil output. Good quality oil, longer lifetime, and easy to clean.
3.National Patent Unique Smoke Scrubbers: More efficient removal of the acid gas and dust of the smoke by neutralization, purification and absorption, environmental friendly without pollution.
4.National Patent Carbon Black Discharging System: Speedy fully enclosed Auto-discharging under high temperature, avoiding carbon black pollution, saving time.
5.Sync Gas Recycling System: Fully burned after recycling and utilization, saving fuel and preventing pollution.
6.Automatic Submerged welding technology, ultrasonic nondestructive testing, both manual and the automatic safety devices
7.Direct Heating System: Enlarging heating square to lengthen the lifespan of the reactor and easy to control the temperature.
8. National Patent, unique heat insulation shell: high efficiency temperature keeping, excellent energy-saving effect.
| NO | Item | Content | ||
| 1 | Model | XY-7-P | XY-8-P | XY-9-P |
| 2 | Door type | Full door oper | Full door oper | enclosed auto-feeder |
| 3 | Raw material | Rubber/plastic products etc | Rubber/plastic products etc | Rubber/plastic products etc |
| 4 | Structure | Horizontal rotation tyre | Horizontal rotation tyre | Horizontal rotation tyre |
| 5 | Reactor size |
2.2*6.0m 2.5*6.6m 2.5*7.5m |
2.2*6.0m 2.5*6.6m 2.5*7.5m |
1.7*8.8m 1.7*13.2m |
| 6 | Capacity for one batch |
5-6MT/8-10MT 10-12MT |
5-6MT/8-10MT 10-12MT |
20-50MT |
| 7 | Oil yield | 40-45% | 40-45% | 40-45% |
| 8 | work pressure | normal | normal | slightly negative |
| 9 | Reactor rotation speed | 0.4R/M | 0.4R/M | 0.5-1.2R/M |
| 10 | Fuel choice | coal,wood,gas ,oil | coal,wood,gas ,oil | coal,wood,gas ,oil |
| 11 | Power | 18-22kw/h | 18-25kw/h | 18-25kw/h |
| 12 | Cooling method | Cycling water | Cycling water | Cycling water |
| 13 | Type of drive | external annular gear | external annular gear | external annular gear |
| 14 | Heating method | Direct heating | Direct heating | Direct heating |
| 15 | Type of installation | Without foundation | with foundation/integrated base | with foundation/integrated base |
| 16 | NOISE dB(A) | less than85 | less than85 | less than85 |
| 17 | Operating mode | intermittent operation | intermittent operation | continuous operation |
| 18 | Total weight(MT) | 25-40 | 25-40 | 90-100 |
Usage of the end products:
Crude carbon black ----make briquettes for heating use;make bricks to pave street
Pyrolysis fuel oil------ sell directly for heating oil; to refine into diesel grade oil.
Sync gas ------recycle to heat machine during production.
a. We have professional service staff who are responsible for your plants besides
our sales managers and technicians.
b. Engineers available to go overseas for plant installation.
c. Quality warranty period: one year for the main reactor of pyrolysis machines and
lifetime maintenance for completing machines.
